Current Layout by Pete Smith

Layout Name:

"Loon Lake Railway & Navigation Co"

Layout Status:

active

Track Type:

Sn3

Layout Space:

21' x 26'

Layout Style:

Around-the-room, C-shaped

Track Manufacturer:

Tomalco

Rail Size:

code 70, 55 (logging)

Min. Turnout Frog:

#6

Min. Radius:

30"

Ruling Grade:

2%

Track Height(s):

48" to 54"

Mainline Track Length:

150'

Era:

1938

Setting:

Pacific Northwest

Railroad(s) Modeled:

freelance

Control System:

DCC (CVP - EasyDCC)

Featured In:

Railroad Model Craftsman, Jul 2020

Model Railroad Hobbyist, Feb 2020, pg 43

Railroad Model Craftsman, Nov 2012, pg 42

Other Links:

Videos:

Three-truck Climax #16 hauls a string of log cars to the mill while 2-truck Climax #4 can be seen in the background heading down the switch back on its way to Camp 8 with a caboose in tow. Mainline turnouts are regular point turnouts, and back-woods turnouts are stub turnouts. The locomotives and rolling stock are P-B-L products. The geared locomotives are brass, as is the caboose at the far end of the log train. The caboose in the upper right is an injection-moulded plastic kit. The skeleton log cars are white metal kits. The photograph was taken using a tripod-mounted iPhone 11 camera. Pete took eight photos, each with a different focal point and combined them with a photo stacking software called Helicon Focus to achieve the exceptional depth of field. Pete's photo appeared on the inside cover of the April 2023 issue of Railroad Model Craftsman in the NASG promotional ad campaign.


(copyright © Pete Smith; used by permission)
